XPRINTER370B

Primary Function & Dual-Mode CapabilityPrinter Classification: Dual-Mode 2-in-1 Thermal Printer.Intended Use: This hybrid printer serves two distinct functions that can be switched via software configuration:Label Printing Mode (Primary): For printing adhesive barcode stickers, price tags, shelf labels, and product tags for retail, pharmacies, and inventory management.Receipt Printing Mode (Secondary): Acts as a standard point-of-sale receipt printer to print payment bills and cash register vouchers on continuous paper.Important Shipping Label Warning: Supports a maximum media width of 82 mm, meaning it is NOT suitable for large standard shipping labels (like 4×6 inches / 100×150 mm). However, it can print smaller, modified shipping labels up to 8 cm wide.📄 Printing & Performance SpecificationsPrint Method: Direct Thermal (Inkless / No ribbon or toner required).Resolution: 203 DPI (8 dots/mm) ensuring clean text, crisp graphics, and highly scannable barcode lines.Print Speed: Up to 152 mm/s (6 inches/sec) maximum for both modes (high-speed processing).Max Print Width: 76 mm maximum actual print area.Max Print Length: 1778 mm.Memory: 4MB SDRAM (volatile memory) and 4MB FLASH storage for design layouts, fonts, and graphics.📜 Media & Paper Roll SpecsSupported Media: Thermal label paper (with spacing/Gaps), continuous adhesive paper, black mark labels, and standard continuous thermal receipt paper.Media Width Range: Supports flexible roll widths from 20 mm up to 82 mm maximum.Max Paper Roll Diameter: External diameter up to 100 mm to maximize paper capacity and reduce roll replacement frequency.Smart Sensors:Gap Sensor (Transmissive): For automatic label length and border detection.Black Mark Sensor (Reflective).Print head temperature sensor (Thermistor) for overheating protection, paper-end sensor, and cover-open sensor.🔌 Interfaces & Software SupportStandard Interfaces: Built-in USB port + Serial port (RS232) for direct connection to PCs or laptops.Cash Drawer Port: RJ11 interface (DC 24V / 2.5A) to trigger and open cash drawers automatically.Emulation / Command Set: Supports TSPL commands for label/sticker configuration and ESC/POS commands for receipt printing.OS Support: Fully compatible with Windows and Linux operating systems.Design Software Compatibility: Natively supports BarTender software for professional barcode design.Barcode Compatibility: Supports all standard 1D barcodes and 2D barcodes including QR Codes and Data Matrix.⚡ Physical & Electrical CharacteristicsDimensions: 231 mm (D) × 163 mm (W) × 151 mm (H).Net Weight: Approx. 1.50 kg.Power Supply: Internal power supply unit (Input: AC 100-240V, 50-60Hz | Output: DC 24V / 2.5A).
